Laminar Flow Box and Clean Room Passbox Mechanical Interlock Pass Box/Pass Box with Laminar Flow

The pass thru box is a critical part of the product transfers which occur in every cleanroom. Although simple in design, the use
of a pass box is essential to the maintenance of the high level of cleanliness within the cleanroom. The pass box significantly limits
the amount of outside air exposed to the clean zone. With the use of either a mechanical or electrical interlock system, the cleanroom
is protected from the cross-contamination which would occur if both doors were to open simultaneously. Atmos-Tech constructs
Pass-Thrus for small or large parts, wheeled carts, and even personnel.

ModelPH-555PH-666PH-575
Working area W*H*D(mm)500*500*500600*600*600500*700*500

External Dimension(mm)

720*950*580820*1070*680720*1170*580
Interlock systemElectromagnetism interlock
Sight Glass Dimension5mm Tempered Glass
HEPAMechanical Sealing/Gel-type Sealing
DOPOptional
Diff.Pre.GaugeOptional
UV LampOptional 1pcs

Lighting Lamp

Optional 1pcs

Power

AC220V,1ø,50Hz(customized)

Material

1.SUS304;2.Powder coated of external steel plate,SUS304 Of inner side

Products Standard

Q/320507 LDH007-2016
